de.uni_leipzig.wifa.iwi.mr3.dao.neo4j.impl
Class AbstractNeoSaveProcessor

java.lang.Object
  de.uni_leipzig.wifa.iwi.mr3.dao.neo4j.impl.AbstractNeoSaveProcessor

All Implemented Interfaces:

SaveProcessor

Direct Known Subclasses:

PhaseOneSaveProcessor, PhaseTwoSaveProcessor

public abstract class AbstractNeoSaveProcessor
extends Object
implements SaveProcessor

Abstract save phase processor for neo4j storage.

This class contains all the methods all neo4j specific implementations need.

Constructor Summary

AbstractNeoSaveProcessor()

Method Summary

protected org.neo4j.api.core.Node	createNode() Create a node.
protected org.neo4j.api.core.Node	createNodeWithRelationship(org.neo4j.api.core.Node node, EcoreRelationshipType relType, boolean ordered) Creates a node and binds it by a specified relationship to the given node.
void	dispatch(org.eclipse.emf.ecore.EObject element, Map<org.eclipse.emf.ecore.EObject,Object> registry) Dispatch the current element to its handler.
NeoHelper	getHelper() Getter.
protected org.neo4j.api.core.Node	getNodeFromRegistry(org.eclipse.emf.ecore.EObject element, Map<org.eclipse.emf.ecore.EObject,Object> registry) Determine a node from the registry.
void	process(org.eclipse.emf.ecore.resource.Resource resource, Map<org.eclipse.emf.ecore.EObject,Object> registry) Process.
void	setHelper(NeoHelper neoHelper) Setter.

Methods inherited from class java.lang.Object

clone, equals, finalize, getClass, hashCode, notify, notifyAll, toString, wait, wait, wait

Methods inherited from interface de.uni_leipzig.wifa.iwi.mr3.dao.SaveProcessor

process, process, process, process, process, process, process, process, process, process, process, process, process, process

Constructor Detail

AbstractNeoSaveProcessor

public AbstractNeoSaveProcessor()

Method Detail

setHelper

public void setHelper(NeoHelper neoHelper)

Setter.

Parameters:

neoHelper - the helper to set

getHelper

public NeoHelper getHelper()

Getter.

Returns:

the helper

process

public void process(org.eclipse.emf.ecore.resource.Resource resource,
                    Map<org.eclipse.emf.ecore.EObject,Object> registry)

Process.

Specified by:

process in interface SaveProcessor

Parameters:

resource - Resource

registry - Node cache

See Also:

SaveProcessor.process(org.eclipse.emf.ecore.resource.Resource, java.util.Map)

dispatch

public void dispatch(org.eclipse.emf.ecore.EObject element,
                     Map<org.eclipse.emf.ecore.EObject,Object> registry)

Dispatch the current element to its handler.

The order of dispatch types dependends on type hierarchy. Special types must be checked earlier then generally types.

Specified by:

dispatch in interface SaveProcessor

Parameters:

element - Element to dispatch

registry - Node cache

getNodeFromRegistry

protected org.neo4j.api.core.Node getNodeFromRegistry(org.eclipse.emf.ecore.EObject element,
                                                      Map<org.eclipse.emf.ecore.EObject,Object> registry)

Determine a node from the registry.

Parameters:

element - Element for what we need a node.

registry - Node cache

Returns:

Node

createNodeWithRelationship

protected org.neo4j.api.core.Node createNodeWithRelationship(org.neo4j.api.core.Node node,
                                                             EcoreRelationshipType relType,
                                                             boolean ordered)

Creates a node and binds it by a specified relationship to the given node.

Parameters:

node - the node

relType - the relationship type

ordered - true if node will be created with ordering position value

Returns:

the created and bound node

createNode

protected org.neo4j.api.core.Node createNode()

Create a node. Optionally the node gets a position ordering value.

Returns:

Node
